MEA-1500

MODULAR ENGINE ANALYSER

De nieuwe SUN MEA afkorting voor Modular Engine Analyser is multifunctioneel en biedt u meer mogelijkheden dan welke motortester dan ook in deze prijsklasse. Als u de MEA bezit, bent u de technische problemen de baas. Door de ruime keuze aan mogelijkheden hebt u altijd de juiste hulp bij de hand.

MEA-1500 SL

Introduction

General information

The modular engine analyzer, Model MEA-1500 SL, displays test data for the detection of abnormal operating conditions in gasoline internal-combustion engines. It is microprocessor-controlled and electronically self-calibrating. Testing is accomplished through:

• a 12 inch oscilloscope ("scope") that displays ignition, alternator and electronic systems signal waveforms.
• a 12 inch video display unit (VDU) that displays digital test data and plain language instructional messages which provide assistance in operating the tester.
• a remote control that permits operation of both the VDU and scope from behind the wheel or under the hood.

The analyzer's standard and optional test capabilities and hardware are shown below. The MEA-1500 SL Operator's Manual presents illustrated instructions for operating the engine analyzer with all options installed. Refer to "Accessories" for a complete listing with part numbers of standard and optional accessories.

MEA-1500 SL Test Capabilities

STANDARD	OPTIONAL
RPM Dwell Strobe Timing Battery & Distributor volt Scope volt/kilovolt/millisec Pinpoint volt/ohm Frequency Duty cycle	HC, CO, CO2, O2 emission module Amps/Vacuum Oil temperature Diesel SUN Data Link communication Lambda and AFR

MEA-1500 SL Hardware

STANDARD	OPTIONAL
Analyzer console Remote control Test-lead boom Leads, connector Adaptor set	Industry-standard printer 4 Gas analyzer Amps/Vacuum kit Oil temperature kit SUN Data Link communication Diesel test kit
